SHUTTLE

Shuttle XPC AiO P55U3 i3 Barebone Touch

Behuizingstype: All-in-one - Schermgrootte: 39,6 cm (15,6") - Processormodel: Intel Core i3-1315U, 1,2 GHz - Besturingssysteem: Zonder... meer
(Product beoordelen)
€ 612,99

Brutoprijs: € 741,72 incl. € 128,73 btw excl.

Bestel nu en we verzenden dit artikel zodra het beschikbaar is.

Momenteel niet op voorraad.

Barebone All-in-One with 15.6" for POS, POI and Kiosk applications. RAM: 2 x 262-pin SO-DIMM slot Supports DDR5-5200 (PC5-41600) SDRAM with 1.1 V Also supports memory modules with high frequencies Supports dual-channel mode Supports max. 48 GB per slot Max. total capacity of 96 GB Supports unbuffered DIMM modules (non- ECC or registered) SSD: This product comes with two M.2-2280 Key-M slots - Supports M.2 cards 22 mm wide and 80 mm long (Type 2280) - Supports one M.2 SSD card with PCle/NVMe interface - The second M.2 SSD card must have a SATA interface - The second slot can also be used for the optional WWN04 kit to install a 4G/5G network module. The system comes without an OS. It is compatible with: - Windows 11 (64-bit) - Windows 10 (64-bit) - Linux - 64-bit Custom configurations available on request.

Shuttle XPC AiO P55U3 i3 Barebone Touch

Product
ProducttypeAll-in-one PC
Fabrieksgarantie3 jaar Carry-In (Details: zie website van fabrikant)
Beeldscherm
Schermgrootte39,6 cm (15,6")
SchermoppervlakGlanzend
Fysieke resolutie1.920 x 1.080 FHD
Helderheid250 cd/m²
TouchscreenMulti-touch
Touch-technologieCapacitief
Design
KleurZwart
Processor
ProcessorfamilieIntel Core i3
ProcessormodelIntel Core i3-1315U, 1,2 GHz
Moederbord chipsetin CPU geïntegreerd
Werkgeheugen
Type werkgeheugenDDR5
Kloksnelheid5.200 MHz
Geheugenbanken bezet / totaal0 / 2
Max. werkgeheugen96 GB
Videogeheugen
VideokaartIntel UHD Graphics
Connectivity
Vrije slots2 x M.2 2280 PCIe
Totaal aantal slots2 x M.2 2280 PCIe
NetwerkkaartEthernet 10/100/1000 Mbit/s
Aansluitingen1 x HDMI, 1 x koptelefoon, 1 x microfoon, 1 x RJ45, 1 x VGA, 2 x serieel, 2 x USB-A 3.1, 4x USB-A 3.0
Draadloze functiesBluetooth, WLAN
Besturingssysteem
BesturingssysteemZonder
Drives
DrivesZonder
Camera
FrontcameraSingle
Resolutie camera voorzijde2 MP
Uitrusting
Luidspreker2 x 2W (stereo)
Netvoeding90 Watt, Extern
Montage
VESA montagestandaard100 x 100 mm
Security
BeveiligingKensington Standard Slot
BeschermingsgraadIP54 (front)
Inbegrepen in de levering
Bij de levering inbegrepenNetvoeding (90 W)
Fysieke eigenschappen
BehuizingstypeAll-in-one
Afmetingen (b x h x d)394 x 273 x 40 mm
Uitvoering
UitvoeringEuropa

Datasheets

Shuttle XPC AiO P55U3 i3 Barebone Touch - Datablad 1

Bestandstype: PDF

Bestandsgrootte: 2.24 MB
